5LPM PSA Oxygen tower Components

Spare parts and corresponding quantities: (1) DN52 aluminum alloy cylinder (52 × 310mm/requires machining of thread M5×0.8) :2PCS ; (2) Reinforced nylon end cap with thread Female PT1/4:4PCS ; (3) Fluorine rubber sealing ring: 4PCS ; (4) Breathable filter cotton: 4PCS ; (5) Porous breathable board:4PCS ; (6) Hold-down spring:2PCS ; (7) Locking nut:16PCS ;

Model Number：OXY-TC-5L.52310
Colors：
Views：4
：
Share this:

Overview

We use an aluminum alloy cylinder with an inner diameter of 52mm and a height of 310mm to make the oxygen tower.

Other accessories include end caps, sealing rings, porous mesh plates, breathable filter cotton, compression springs, and locking nuts.

These components can be effectively used on 5L small household oxygen concentrators or small industrial ozone equipment. When the flow rate of oxygen output reaches 5 liter/minute, the corresponding oxygen output concentration can reach 93 ± 3%.

Specifications

Spare parts and corresponding quantities:
(1) DN52 aluminum alloy cylinder (52 × 310mm/requires machining of thread M5×0.8) :2PCS ;
(2) Reinforced nylon end cap with thread Female PT1/4:4PCS ;
(3) Fluorine rubber sealing ring: 4PCS ;
(4) Breathable filter cotton: 4PCS ;
(5) Porous breathable board:4PCS ;
(6) Hold-down spring:2PCS ;
(7) Locking nut:16PCS ;
